Qubic System / Official range
Qubic System QS-TP1 Traction Pro Motion Platform
£5799.99
Price includes UK VAT. No import fees.
✓ Order by 2pm — dispatched the same working day
✓ Free tracked UK delivery on this item
✓ 14-day returns · full manufacturer warranty
Secure checkout · Card, Apple Pay & Google Pay
Product overview
A two-axis surge and yaw platform that moves the whole cockpit to recreate braking, acceleration and rear traction loss. Use it on its own or combine it with a QS-210 or QS-220 actuator set for five axes. Fits aluminium profile cockpits 540–756 mm wide; the QS-MC6 controller is sold separately.
Key specifications
14 listed
- 01Architecture – 2DOF (surge and yaw)
- 02Maximum payload – 250 kg
- 03Surge travel – ±30 mm
- 04Yaw travel – ±8°
- 05Maximum velocity – up to 400 mm/s
- 06Maximum acceleration – up to 0.6 G
- 07Latency – under 8 ms
- 08Vibration range – 0–100 Hz
- 09Dimensions with cockpit adapters – 1271 × 850 × 273 mm
- 10Platform weight – 86 kg
- 11Power – 120/230 V AC, single phase
- 12Connections – USB and Ethernet
- 13Cockpit width – 540–756 mm aluminium profile
- 14Controller – QS-MC6, sold separately
